Hydraulic Drive Motor BMS Transmission Engines 4 Bolt Rhombus, 14 Teeth Spline
Description:
We are the specialized manufacturer of orbital hydraulic motor , we can produce kinds of motor with different models and technical parameters. Which has provided wide choice to meet customer’s needs.Meanwhile, Our products manufactured can be completely interchanged with SAUER OMP, OMR, OMH, OMS, OMT AND OMV series.
Features:
1. Advanced design in disc distribution flow, which can automatically compensatein operating.
2. Various kinds of flange, output shaft and oil port mounting dimension.
3. Shaft seal can bear high pressure of back and the motor can be used in parallel or inseries.
4.Special design in the driver-linker and prolong operation life.
5. The output shaft adopts in tapered roller bearings thatpermit high axial and radial forces. The can offers capacities of highpressure and high torque in the wide of applications.
Applications:
BM hydraulic motors are widely applied in agriculture machinery, fishing machinery, plastic industry, mining, and construction machinery.
Main Specifications:
| Type | BMS
BMSE
80 | BMS
BMSE
100 | BMS
BMSE
125 | BMS
BMSE
160 | BMS
BMSE
200 | BMS
BMSE
250 | BMS
BMSE
315 | BMS
BMSE
375 |
Geometric displacement
(cm3 /rev.) | 80.6 | 100.8 | 125 | 157.2 | 200 | 252 | 314.5 | 370 |
| Max. speed (rpm) | cont. | 800 | 748 | 600 | 470 | 375 | 300 | 240 | 200 |
| int. | 988 | 900 | 720 | 560 | 450 | 360 | 280 | 240 |
| Max. torque (N·m) | cont. | 190 | 240 | 310 | 316 | 400 | 450 | 560 | 536 |
| int. | 240 | 300 | 370 | 430 | 466 | 540 | 658 | 645 |
| peak | 260 | 320 | 400 | 472 | 650 | 690 | 740 | 751 |
| Max. output (kW) | cont. | 15.9 | 18.8 | 19.5 | 15.6 | 15.7 | 14.1 | 14.1 | 11.8 |
| int. | 20.1 | 23.5 | 23.2 | 21.2 | 18.3 | 17 | 18.9 | 17 |
| Max. pressure drop (MPa) | cont. | 17.5 | 17.5 | 17.5 | 15 | 14 | 12.5 | 12 | 10 |
| int. | 21 | 21 | 21 | 21 | 16 | 16 | 14 | 12 |
| peak | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 20 | 18.5 | 14 |
| Max. flow (L/min) | cont. | 65 | 75 | 75 | 75 | 75 | 75 | 75 | 75 |
| int. | 80 | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
| Max. inlet pressure (MPa) | cont. | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| int. | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 |
| Weight (kg) | 9.8 | 10 | 10.3 | 10.7 | 11.1 | 11.6 | 12.3 | 12.6 |
* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.
Model Crossing:
| HANJIU | M+S | EATON | | ROSS | WHITE | PARKER | SAM | BOSCH | |
| HYDRAULIC | HYDRAULIC | CHAR LYNN | TRW | CROSS | BREVINI | REXROTH | |
| | | |
| BMM | MM | | OMM | | | | | MGX | |
| | MLHK | J SERIES | | - | - | - | BGM | | |
| BMP/BM1 | MP | | OMP | MF | WP | TC | BG | MGP, GMP | |
| | | | | | | TE | | | |
| | HP | H SERIES | DH | MG | RS | TB | | | |
| BMR/BM2 | MR | | OMR | MB | WR | | BR | MGR, GMR | |
| | HR | S,T SERIES | DS | | RE | TF | | | |
| | MLHRW, RW | W SERIES | OMEW | | | | | | |
| BMH/BM4 | MH | | OMH | | | | | | |
| | MLHH | | | ME | | | | | |
| | HW, HWF | | | | RE | TG | | | |
| BMS/BM5 | MS, MSY | | OMS | | | TG | | MGS, GMS | |
| | | | | | | | HPR | | |
| | MLHS | 2000 SERIES | | ME | RE | | | | |
| BMT/BM6 | MT | | OMT | | | | | MGT, GMT | |
| | MLHT | 6000 SERIES | | MJ | | | HT | | |
| | MTM | | TMT | | | | | | |
| BMV | MV | | OMV | | | | | MGV, GMV | |
| | MLHV | 10000 SERIES | | | | | | | |
