BMV/OMT/10K Series Heavy Duty Orbital Motor For Soil Compactor, skid loader
Features:
1. Compact in design with disc valving motor and geroler type
2. Orbital motor for heavy applications
3. Totally interchangeable with , Eaton,and M+S etc.
4. Shaft with taper roller bearings ensures high static and dynamic bearing capacity.
5. Orbit kit with rollers - Separate integrated valve
6. High volumetric and mechanical efficiency
7. High pressure capacity shaft seal design
8. Design and manufacturing of the spline and drives give the motor durability
9. Wide variety of mounting flanges, shafts,ports and speed provides design flexibility
10. Direction of shaft rotation and speed can be controlled easily and smoothly
11. Best combination of high efficiency and ecnomy in medium duty applications
Applicaions:
The BMV orbital motor can widely use for the following machines:
* Soil Compactor
* skid loader
* Food Processing
* drilling rig machine
* transport mixer
* log splitter
* waste plant conveyors
Main Specifications:
| Type | BMV 315 | BMV 400 | BMV 500 | BMV 630 | BMV 800 | BMV 1000 |
| Geometric displacement (cm3 /rev.) | 333 | 419 | 518 | 666 | 801 | 990 |
| Max. speed (rpm) | cont. | 510 | 500 | 400 | 320 | 250 | 200 |
| int. | 630 | 600 | 480 | 380 | 300 | 240 |
| Max. torque (N·m) | cont. | 920 | 1180 | 1460 | 1660 | 1880 | 2015 |
| int. | 1110 | 1410 | 1760 | 1940 | 2110 | 2280 |
| peak | 1290 | 1640 | 2050 | 2210 | 2470 | 2400 |
| Max. output (kW) | cont. | 38 | 47 | 47 | 40 | 33 | 28.6 |
| int. | 46 | 56 | 56 | 56 | 44 | 40 |
| Max. pressure drop (MPa) | cont. | 20 | 20 | 20 | 18 | 16 | 14 |
| int. | 24 | 24 | 24 | 21 | 18 | 16 |
| peak | 28 | 28 | 28 | 24 | 21 | 18 |
| Max. flow (L/min) | cont. | 160 | 200 | 200 | 200 | 200 | 200 |
| int. | 200 | 240 | 240 | 240 | 240 | 240 |
| Weight (kg) | 31.8 | 32.6 | 33.5 | 34.9 | 36.5 | 38.6 |
* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.
Model Crossing:
| HANJIU | M+S | EATON | | ROSS | WHITE | PARKER | SAM | BOSCH |
| HYDRAULIC | HYDRAULIC | CHAR LYNN | | TRW | CROSS | | BREVINI | REXROTH |
| | | | | | | | | |
| BMM | MM | | OMM | | | | | MGX |
| | MLHK | J SERIES | | - | - | - | BGM | |
| BMP/BM1 | MP | | OMP | MF | WP | TC | BG | MGP, GMP |
| | | | | | | TE | | |
| | HP | H SERIES | DH | MG | RS | TB | | |
| BMR/BM2 | MR | | OMR | MB | WR | | BR | MGR, GMR |
| | HR | S,T SERIES | DS | | RE | TF | | |
| | MLHRW, RW | W SERIES | OMEW | | | | | |
| BMH/BM4 | MH | | OMH | | | | | |
| | MLHH | | | ME | | | | |
| | HW, HWF | | | | RE | TG | | |
| BMS/BM5 | MS, MSY | | OMS | | | TG | | MGS, GMS |
| | | | | | | | HPR | |
| | MLHS | 2000 SERIES | | ME | RE | | | |
| BMT/BM6 | MT | | OMT | | | | | MGT, GMT |
| | MLHT | 6000 SERIES | | MJ | | | HT | |
| | MTM | | TMT | | | | | |
| BMV | MV | | OMV | | | | | MGV, GMV |
| | MLHV | 10000 SERIES | | | | | | |
