120 Liter P120 Three Spool Monoblock Control Valve G 1" Open Center Spool

Name: 120 Liter P120 Three Spool Monoblock Control Valve G 1quot Open Center Spool
Brand: HANJIU
Price: 1 USD

Buy cheap 120 Liter P120 Three Spool Monoblock Control Valve G 1" Open Center Spool product

Brand Name : HANJIU

Model Number : 3P120

Certification : CE

Place of Origin : CHINA

MOQ : 100 Sets

Price : Contact the seller to get a quote

Payment Terms : L/C, T/T, Western Union, Western Union

Supply Ability : 300000 sets per year

Delivery Time : 15 - 45 work days

Packaging Details : Carton, Box, Pallets

Item : Hydraulic valves

Model : 3P120

Apply to : flow generators, flow consumers

Spool : 3

MAax operation pressure : 350 bar

Nominal flow : 120 LPM

Contact Now

120 liter monoblock control valve, P120 , three spool , G 1" , open center spool

Directional control valves are one of the core elements in a hydraulic system. They help directing the fluid to different components such as hydraulic cylinders or motors.

Directional control valves perform three functions:

Stop fluid flow

Allow fluid flow

Change direction of fluid flow.

There is a part called «spool» inside control valve which can be operated mechanically or electrically. The movement of the spool lets oil flow or blocks the oil flow in other words it controls the movement of fluid. Hanjiu provide monoblock directional control valves with different capacities and spool control options.

* Spool is open center “A” spool with spring return. Working port threads (A & B) are G 1"

* Max. Pressure P: 250 bar, T: 50 bar, A-B: 300 bar

AMBIENT TEMPERATURE	-40 … +60
oC	-40 … +60
VISCOSITY	12 … 800
mm2/s	12 … 800
FLUID TEMPERATURE	-15 … +80
oC	-15 … +80
FILTRATION	10 to NAS 1638
MAX OPERATING PRESSURE	315
bar	315
BACK PRESSURE	50
bar	50
NOMINAL FLOW	120
L/min	120
LEAKAGE (A, B-T)	30 cm3/min at 120 bar
SPOOL STROKE	10
mm	10
ACTUATING FORCE	< 300
N	< 300

120 Liter P120 Three Spool Monoblock Control Valve G 1" Open Center Spool
