Home > Orbit Hydraulic Motor >

Medium Duty Drive Engines Orbit Hydraulic Motor For Wheel Drives Augers Mixers Winch Drives

Product Categories
Shijiazhuang Hanjiu Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Medium Duty Drive Engines Orbit Hydraulic Motor For Wheel Drives Augers Mixers Winch Drives

  • 1
  • 2
  • 3

Brand Name : HANJIU

Model Number : 600200A8220AJAAD

Certification : CE

Place of Origin : China

MOQ : 100 Pieces

Price : 165 USD

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 10000 pieces per year

Delivery Time : 55 work days

Packaging Details : Box, Pallet

Item : Orbit Hydraulic Motor

OEM # : 600200A8220AJAAD

Manufacturer : Hanjiu

Displacement : 200ml/r

Mounting flange : 4-hole wheel flange

Shaft type : Straight

Contact Now



Medium Duty Drive Engines for wheel drives, augers, mixers, winch drives







This is a medium duty drive engines which is compatible with White DR series. It widely used on wheel drives, augers, mixers, winch drives, swing drives, grapple heads, feed rollers, broom drives, chippers, mining equipment, forestry equipment and more.





Specification:



Code Displacement Max. Speed Max. Flow Max.Torque
  cm3(in3/r) rpm lpm(gpm) Nm(lb-in)
200 204 [12.4] 470 560 95 [25] 114 [30] 554 [4900] 644 [5700]
260 261 [15.9] 360 440 95 [25] 114 [30] 745 [6590] 859 [7600]
300 300 [18.3] 320 380 95 [25] 114 [30] 842 [7450] 972 [8600]
350 348 [21.2] 270 320 95 [25] 114 [30] 972 [8600] 1107 [9800]
375 375 [22.8] 250 300 95 [25] 114 [30] 1085 [9600] 1243 [11000]
470 465 [28.3] 200 240 95 [25] 114 [30] 1107 [9800] 1316 [11650]
540 536 [32.7] 180 210 95 [25] 114 [30] 1034 [9150] 1277 [11300]
750 748 [45.6] 130 150 95 [25] 114 [30] 1040 [9200] 1390 [12300]









Overview:



This Series drive engine is an excellent medium size motor for applications with high- duty cycles or frequent direction reversal. The drain design produces a number of benefits including reduction of pressure on the shaft seal and the ability to provide a cooling loop for the system. The flow also lubricates the vital drive components, extending motor life. An internal drain option is also available. A laminated manifold and three-zone orbiting valve are used to produce higher overall efficiencies and more usable power. A steel faced seal in the orbiting valve also reduces the risk of the seal extruding or melting, which is possible in competitive designs.







Medium Duty Drive Engines Orbit Hydraulic Motor For Wheel Drives Augers Mixers Winch Drives





Medium Duty Drive Engines Orbit Hydraulic Motor For Wheel Drives Augers Mixers Winch Drives
