High Pressure Turolla Group 2 Gear Motor Snm 2 Key Shaft 0.51in 3,3600 Psi Gear Pump

Brand Name : Hanjiu

Model Number : Hydraulic Gear Pump

Certification : CE

Place of Origin : China

MOQ : 50 units

Price : Negotiable

Payment Terms : T/T, Western Union,Paypal .

Supply Ability : 100,000 units / Year

Delivery Time : 10-15 working days

Packaging Details : Carton packing , with a tray or wooden box if needed .

Product name : high efficiency hydraulic pump

Pressure level : 25MPa

Displacement (ml/r) : 6,8.4,10.8,14.4,16.8,19.2,22.8,25.2

Applications : hydraulic power,construction machines,plastic machines

Direction of rotation : Left , Right

Ports : 7/8 - 14UNF-2B, 1 1/16 - 12UN - 2B

Contact Now

High Pressure Turolla Group 2 Gear Motor SNM 2 key shaft 0.51In3,3600psi Gear pump



The hydraulic gear pump produced by Hanjiu is widely used in various kinds of machinery, such as tractors, excavators, forklifts and other projects as well as agricultural machinery, and is professionally designed for well-known brands of imported machinery, such as Ford, Kubota, Lovol and others.




Main Specifications:





TYPE DISPLACEMENT flow at 1500rev/min max pressure
P1 P2 P3
GHM2A-D-6 4.5 6.4 280 290 310
GHM2A-D-9 6.4 9.1 280 290 310
GHM2A-D-10 7 10 280 290 310
GHM2A-D-13 9.6 13.7 280 290 310
GHM2A-D-16 11.5 16.4 280 290 310
GHM2A-D-20 14.1 20.1 260 270 290
GHM2A-D-22 16 22.8 260 270 290
GHM2A-D-25 17.9 25.5 260 270 290
GHM2A-D-30 21.1 30.1 230 240 260
GHM2A-D-34 23.7 33.7 230 240 260
GHM2A-D-40 28.2 40.1 200 210 230





How to order?



GHM2 TYPE ROTATION SIZE SHAFT PORTS High Pressure Turolla Group 2 Gear Motor Snm 2 Key Shaft 0.51in 3,3600 Psi Gear Pump
  omit   6
  A D COLCKWISE 9
  A3 S COUNTER  CLOCKWISE 10
  BK1 R REVERSIBLE 13
  BK2   16
  BK4   20
  BK7   22
      25
      30
      34
      40
