Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump

  • 1
  • 2
  • 3

Brand Name : HANJIU

Model Number : 109s-50

Certification : CE

Place of Origin : China

MOQ : 5 Pieces

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50000 Pieces One Year

Packaging Details : Carton Box

Product Name : Tractor Hydraulic steering valves

Brand : HANJIU

Displacement : 20cc -80cc

Application : mini forklift,mini tractors,agricultural machinery

Features : Match than ,M+S Hydraulic steering units

Contact Now

hydraulic steering units mini tractors orbitrol steering pump OSPM 50 150L2150 Lawn mower pump



109 series hydraulic steering unit is an integrated orbital steering unit with 4/5 tooth structure.This kind of steering unit has a

small and exquisite structure with integrated check valve, relief valve and shock valves and its mounting dimension conforms

to international standard.This kind of steering unit is widely used in mini vehicles, such as mini forklift, mini tractor (and

other agricultural machinery), mini earthmoving machinery,mini municipal vehicle, etc. It can obtain more steering output torque

through input of less power, with features of easy, flexible and reliable operation.



1. Characteristic Features



1) We are professional manufacturer produce Hydraulic steering units .

2) Quality match than , M+S, Eaton.

3) Match than OEM spare parts code number.

4) Application mini tractors,small tractors,lawn mower



2. Products details





type 109 series
displacement 50cc
function open center reaction
iinput shaft Tapered 1:20 key 5x6.5
ports 9/16-18UNF







If you need other type steering units or details, please contact me and send your product details to me.





3. Specification



Parameters Type 109*-1-***-**-*
Displacement(mL/r) 20 32 40 50 63 80
Rated flow(L/min) 3~20
Rated Pressure(MPa) 12.5
Relief Valve Pressure Settings(MPa) 06,07,08,09,10
Shock Valves Pressure Settings(MPa) 12,13,14,15,16
Steering Torque(N·m) ≤1.8
Max.Cont.Preesure in Line T-PT(MPa) 1
Dimension L(mm) 87 92 96 100 105 113




Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump

Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump

Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump



    Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump

Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump



Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump




Mini Tractors Orbitrol Steering Pump OSPM 50 150L2150 Lawn Mower Pump
